6-Ton electric counterbalanced forklift G2 series CPD type 6.0T

BYD CPD 6.0T large-tonnage electric counterbalanced forklift, built on the brand's mature new energy technology and Seiko manufacturing strength, is specially designed for 6-ton heavy-duty handling scenarios. The equipment has abundant power, stable operation and flexible operation. It can be widely used in industrial manufacturing, warehousing and logistics, cargo transshipment and other scenarios. It is a practical equipment for heavy-duty operations in enterprises.

First, the basic configuration and vehicle parameters

Power and operating performance

       The vehicle is equipped with an AC electronic control system, equipped with dual-drive motors and dual-lift motors. The power of a single drive motor is 18kW, and the power of a single lift motor is 24kW. The power output is stable and strong, with a full-load driving speed of 16Km/h and a no-load driving speed of 17Km/h; the full-load lifting speed is 350mm/s, the no-load lifting speed is 400mm/s, and the full-load falling speed is 500mm/s. The working efficiency is excellent.

       The maximum traction of the vehicle is 32KN at full load and 28KN at no load under 5-minute working conditions; the climbing ability is excellent, with a full load climbing ratio of 15% and a no-load climbing ratio of 20%, which can smoothly handle complex road conditions such as ramps and high and low roads in the factory. The vehicle is equipped with an 80V/840Ah battery with a battery weight of 1200kg and stable battery life, which can meet the needs of long-term continuous operation.

III. Site passing and steering performance

       The vehicle has flexible steering, with a minimum turning radius of 3260mm and an inward turning radius of 1250mm. It can also be turned smoothly in narrow spaces. The site adaptability is strong. When placing 10001200mm horizontal pallets, the required working channel width is 5355mm; when placing 8001200mm vertical pallets, the required working channel width is 5555mm, which is suitable for mainstream storage channel specifications.

IV. Product advantages and applicable scenarios

       The whole vehicle integrates high load, high efficiency and high safety. The new energy electric drive runs energy-saving and environmentally friendly, and the use cost is lower. The body structure is solid, the accessories are durable, the braking, electronic control and other systems operate stably, and multiple designs ensure the safety of the operation. At the same time, combined with ergonomics to create a driving area, the driving experience is good, and it is suitable for long-term continuous operation.
