4.5 ton lithium battery balance forklift EL-Pro45MAX

BYD EL-Pro45MAX 4.5 tons lithium battery counterweight forklift, equipped with self-developed lithium iron phosphate battery, 1 hour fast charge to 80%, battery 5 years/12,000 hours quality assurance, dual drive motor po

Send Inquiry

Product details

Product Overview

BYD EL-Pro45MAX is the flagship product of EL series upgrade, integrating more than 20 years of new energy technology accumulation, specially designed for high-intensity operations in manufacturing, warehousing and logistics, cold chain, food and medicine industries, to solve the traditional internal combustion forklift high pollution, high cost and ordinary electric forklift power shortage and other pain points.

core advantage

Battery system
Independent research and development of lithium iron phosphate battery, no fire and no explosion, cycle more than 4000 times, 1 hour fast charge to 80%, -40 ℃ to 60 ℃ stable work, maintenance-free, battery 5 years/12,000 hours quality assurance.

dynamic performance
: Dual drive motor (215kW), full load climbing 20%, driving speed 20km/h, lifting speed 450mm/s, energy recovery to improve battery life by 15%.

Structural design
Integral cast rear axle, stability safety factor 2.5, load loss height 4000mm, minimum turning radius 2600mm, excellent passability.

Operation and safety

Equipped with suspended seats, electric proportional valve control, wide field of vision, noise ≤75dB (A). Multiple safety protection, intelligent management system supports fleet remote monitoring and fault self-diagnosis.

Cost and service

The energy cost is about 80% lower than that of internal combustion forklifts, and the total operating cost is more than 40% lower in 5 years. The global service network is complete, providing pre-sales consultation, fast delivery, system training and after-sales guarantee.

parameter name	unit	EL-Pro45MAX
Model name	/	EL-Pro45MAX
dynamic form	/	Electric
mode of operation	/	Seat
rated lifting capacity	Q kg	4500
load center distance	c mm	500
Front overhang	x mm	555
wheelbase	y mm	2120
Gross weight (including battery)	kg	6600
Axle load (full load)	kg	9810/1290
Axle load (no load)	kg	3080/3520
Tire form		Solid tire
Front wheel size	mm	300-15
Rear wheel size	mm	7.00-12
Number of front/rear wheels, x = drive wheels		2x/2
front track	b10 mm	1180
rear track	b11 mm	1130
Forward/Back Angle	a / b	5-8
gantry height	h1 mm	2350
Free lifting height	h2 mm	130
Standard gantry lifting height	h3 mm	3000
Maximum height of the gantry (off the ground)	h4 mm	4250
Ceiling height	h6 mm	2360
Seat height (off the ground)	h7 mm	1330
Traction pin height	h10 mm	400
full length	l1 mm	4166
Full length (excluding forks)	l2 mm	3096
total width	b1/b2 mm	1440
Fork size	s/e/l mm	50/150/1070
ISO 2328 compliant fork racks, frames/forms A, B		3A
Fork rack width	b3 mm	1500
Minimum height from the ground at the gantry	m1 mm	172
Minimum height from the ground at the frame	m2 mm	170
Channel width with 1000x1200 horizontal tray	Ast mm	4510
Channel width with 800x1200 vertical tray	Ast mm	4710
minimum turning radius	Wa mm	2755
Inward turning radius	b13 mm	785
Driving speed, load/no load	km/h	18/18
Lifting speed, load/no load	mm/s	380/420
Drop speed, load/no load	mm/s	500/400
Maximum traction, S2 = 5min, load/no load	N	28000/18000
Maximum climbing capacity, S2 = 5min, load/no load	%	18/20
Brake form		hydraulic brake
Drive motor power, S2 = 60min	kw	23.2
Lifting motor power, S3 = 15% ED	kw	36.6
Battery capacity	V/Ah	80/4202
Battery weight	kg	3092
Battery size L/W/H	mm	695/500/6902
VDI cycle type energy consumption	kw/h	13
Electronic control type		AC
Hydraulic system working pressure	bar	18
Noise at the driver	dB (A)	≤80
Traction connection		PIN
