1.5 ton walking electric stacker S15JW-Ei

      BYD S15JW-Ei is a walking electric stacker with a rated load-bearing capacity of 1500kg, designed for storage shelves, workshop material stacking, e-commerce sorting and other scenarios, suitable for high-frequency, short-distance, narrow-channel cargo handling and stacking operations, taking into account practicality, safety and convenience of operation and maintenance.

Airframe design and pass performance

       The vehicle is compact in structure, with a total length of 1850mm, a body width of 860mm, excluding the fork length of 700mm, and a weight of 545kg. It is suitable for narrow channel operation needs. The minimum turning radius is 1500mm, and the width of the right-angle stacking channel is 2332mm when it is suitable for 10001200mm pallets, and 2266mm when it is suitable for 8001200mm pallets. It can work flexibly in small and medium-sized warehouses and narrow passages in workshops to improve storage space utilization. The size of the fork is 62/170/1150mm (thickness/width/length), the outer width is 685mm, and it is suitable for most standard pallets. The height of the fork from the ground after lowering is 90mm, which can be adapted to the needs of conventional ground operations.

Power and performance

      Equipped with 48V/48Ah lithium battery, the battery weight is 20kg, and it can be used at any time of charging, which is suitable for continuous operation needs. Equipped with 48V/1.0kW drive motor and 48V/1.6kW lift motor, the power output is stable. No-load driving speed is 4.5km/h, full-load driving speed is 4.3km/h; no-load lifting speed is 130mm/s, full-load lifting speed is 80mm/s, and the running rhythm is smooth. No-load climbing capacity is 15%, full-load climbing capacity is 6%, and it can be adapted to slight height difference roads such as warehouse gentle slopes and loading and unloading platforms.

Safe and practical configuration

       Standard electromagnetic braking system, sensitive braking response, stable parking, effective avoidance of rolling and sliding problems. The whole car adopts polyurethane tires, the size of the driving wheel is 21070mm, the size of the load-bearing wheel is 8070mm, and the size of the additional wheel is 11050mm. It is wear-resistant and non-slip, and is suitable for a variety of ground working conditions. The handle height can be adjusted in the range of 815-1250mm, which is suitable for different operators' usage habits. The running noise of the whole machine is 75dB (A), which is suitable for indoor working environment.

core product features

1. 1. Adapt to multi-scenario material handling requirements to meet the needs of small and medium-sized warehousing, stacking, and transshipment operations.


2. 2. The lifting/falling speed is controllable, the control is smooth, and the operation rhythm is adaptable.


3. 3. Modular handle design, convenient maintenance of components, reducing operation and maintenance costs.


4. 4. The gantry guide device runs smoothly and is suitable for shelf stacking operations.


5. 5. Three-point structure with side support system to enhance job stability.


6. 6. The integrated iron wheel cover design can withstand external shocks and protect the car body.


7. 7. Integrated multi-braking function for safe and controllable driving.


8. 8. Double lifting limit configuration to enhance job safety protection.


This model is suitable for e-commerce warehousing, supermarket back warehouses, light industrial workshops, small warehouses, etc. It is a practical equipment for stacking and transshipment of small and medium-sized warehouses.
